Software
|
Operating System Options
|
- Windows 8 Pro 64-bit (MUI)
- Windows 7 Professional 32-bit (MUI)
- Windows 7 Professional 64-bit (MUI)
|
Software
|
- Adobe Reader®
- Norton Internet Security™ 2013 (60-day
free trial)1
- CyberLink PowerDirector
- CyberLink PowerDVD
- CyberLink YouCam, DTS® Boost™
- OmniPass Fingerprint application
|
Optional Software
|
- Depending on your configuration, your
system may include:
- CyberLink MakeDisc
- Norton Studio
- Skype for Windows 8
|
Key Specifications Listed
specifications are for the current model only
and NOT for earlier models or revisions to this
product.
|
Processor Options
|
|
Chipset
|
- Mobile Intel® QM77 Express Chipset (with
AMT) or HM76 (without AMT)
|
Memory
|
- Two DIMM slots
- System memory is upgradable to 16 GB
(8 GB x2) of total memory
- DDR3-1600 MHz SDRAM dual-channel memory
module
|
Display |
- 12.5” HD LED backlit display with wide
viewing angles
|
Video Controller |
- Intel® HD 4000 integrated graphics
controller. Uses Unified Memory Architecture
(UMA) built onto motherboard which shares
part of main memory for video memory. The
amount of shared video memory is determined
by the amount of system memory.
|
Maximum Resolution |
- Internal: 1366 x 768 pixel resolution,
16M colours
- External:1920 x 1200 pixel resolution,
16M colours
- Simultaneous: 1366 x 768 pixel
resolution, 16M colours
|
Digitizer Options |
- Depending on configuration of your
system, one of two digitizer options is
included:
- Active digitizer (uses active stylus
input)
- Dual Digitizer, consisting of active
digitizer and capacitive touch panel
(uses active stylus input and two finger
touch input)
- Note: Active digitizer option only
available on Windows 7 Professional
configurations
|
Camera |
- FHD webcam (1920 x 1080 pixels) with
status LED indicator and two digital
microphones
|
Hard Drive Options2 |
- SATA HDD (5400 rpm with shock-sensor
technology): 320 GB or 500 GB
- SATA HDD (7200 rpm with shock-sensor
technology): 320 GB or 500 GB; 320 GB SED
(TCG OPAL Compliant) with SSD cache
- SATA SSD: 128 GB or 256 GB; 128 GB SSD
SED (TCG OPAL Compliant)
|
Modular Bay Options |
- Modular Dual-Layer Multi-Format DVD
Writer
- Modular Blu-ray Triple writer
- Modular Bay Battery
- Weight Saver
|
Audio |
- Realtek ALC269 with (HD) audio
- One stereo headphone jack and one stereo
microphone jack
- Two built-in stereo speakers and two
built-in digital microphones
|
Communication |
- 10/100/1000 Gigabit Ethernet LAN (Intel®
82579-LM for AMT / 82579V for Non-AMT)
|
Wireless Communication Options3 |
- Optional Integrated Intel® Centrino®
Advanced-N 6205 (802.11abgn 2x2) or Atheros
XSPAN HB116 802.11abgn
- Bluetooth V4+LE device
|
User Interfaces |
- Full size anti-microbial spill-resistant
keyboard with 84 keys
- Touchpad cursor control pad with left
and right buttons
- External USB keyboard and mouse support
|
Ports |
- One 15-pin D-SUB connector for VGA
external monitor (see Display
specifications)
- Two USB 2.0 connectors
- One USB 3.0 connector (the USB 3.0 port
also supports the Anytime USB Charge
feature)
- One DC In connector
- One LAN (RJ-45) connector
- One HDMI port
- Docking port (100-pin, to dock with port
replicator)
- One stereo headphone/line-out jack
- One stereo microphone/line-in jack
|
Optional port replicator |
- One 15-pin D-SUB connector for VGA
external monitor
- Four USB 3.0 connectors for input/output
devices
- One LAN (RJ-45) connector
- One DC-in connector
- One DVI-D connector
- One DisplayPort connector
- One Headphone connector
- Docking connector (100-pin, to dock with
system)
|
Card Slots |
- 54 mm Express Card slot for one Express
Card
- SD Card slot
|
Security |
- Fingerprint sensor
- Embedded Trusted Platform Module (TPM)
- iAMT Support (using Intel® vPro™
technology)
- Lock-slot
- Computrace/LoJack support (service
required)
- Hard drive and BIOS password protection
- Intel® AT (anti-theft) technology
support
|
Battery4 |
- Main battery Lithium ion (72 Wh); up to
9 hours and 50 minutes
- Optional Lithium ion modular bay battery
(6-cell, 28 Wh): up to 13 hours and
40 minutes
|
AC Adapter |
- Autosensing 100-240 V AC, 80 W, 19 V DC,
4.22 A
|
Dimensions / Weight |
- Approx. 12.43”(w) x 9.17”(d) x 1.32”(h)
(1.48” includes rubber feet)
- Active digitizer model, without optical
drive: 3.86 lbs
- Dual digitizer model, without optical
drive: 3.97 lbs
|
Operating Temperature |
- 41°F to 95°F / 5°C to 35°C (ambient
temperature)
- 20% to 85% relative humidity,
non-condensing
|
Non-operating Temperature |
- 5°F to 140°F / -15°C to 60°C
- 8% to 85% relative humidity,
non-condensing
|
Compliance & Service Information
|
Compliance
|
- FCC Part 15 Class B VCCI
- FCC Part 15E
- IC ICES-003 Class B
- RSS-210
- UL-cUL Listed
|
Warranty5 |
- One or three year International Limited
Warranty on select corporate configurations
- 24/7 technical support
|
- Preinstalled with a free 60-day trial
version of Symantec Norton Internet Security
2012. The 60-day trial version is activated
upon user’s acceptance of software license
agreement. After 60 days, the user must
purchase a subscription from Symantec to
download latest virus definitions.
- One gigabyte (GB) = one billion bytes;
accessible capacity will be less and actual
capacity depends on the operating
environment and formatting.
- Wireless service is not included with
your notebook/ tablet PC. Activation, credit
approval, and 2-year minimum commitment
required. Monthly service fee, taxes,
surcharges are extra. Actual connectivity is
subject to wireless service provider’s
coverage area and may be affected by
equipment, topography, signal strength,
environmental considerations, and other
factors. Service may vary significantly
within buildings. Coverage not available
everywhere — see wireless carrier’s coverage
map for details. Terms and Conditions and
additional restrictions apply. A GPS
application (compatible with NMEA v3.1 or
later) must be purchased separately.
- Battery life tested using MobileMark
2007 and may include audio muted. Battery
life will vary depending on the product
configuration, product model, application
loaded on the product, power management
settings on the product, Operating System,
and the product features used by the
customer. As with all batteries, the maximum
capacity of the installed batteries will
decrease with time, usage, and how often the
batteries are charged by the user.
- Service and warranty turnaround time may
vary by country and product. The
International warranty is only valid for
products purchased in North, Central, and
South America.
Specifications are subject to change without
notice.
|
